HGLRC Sector X5 FR 5" 6S Analog
Characteristics
* Replaceable arms for quick disassembly without disassembling the entire frame
* A fixed power socket for convenience and protection of the power cord from being cut by the propellers
* Pre-installed GPS for added safety in the distance with GPS save mode
*Dust straps covering both sides to better protect your rig and keep it clean
*CNC aluminum side plates combined with 3D printed parts to make your drone look awesome!
Product Name: HGLRC Sector X5 FR Analog Version
Weight: 407.7g
Specifications
HGLRC Sector X5 FR
Freestyle frame model: 5 inches
Frame distance: 210mm
Size: 199*178mm
- Zeus F722 mini FC
CPU: STM32F722 RET6
FC Firmware: BF HGLRCF722
Input voltage: 3-6S Lipo - Zeus 45A V2 4in1 ESC
Input voltage: 3-6S Lipo
Constant current:45A
Peak Current:55A(10 Sec)
ESC Firmware:BL_S (FH-40) - Zeus 800mW VTX
Output power: PIT/25/100/200/400/
800mW Input voltage: DC6-26V
Antenna: MMCX - Caddx Ratel 2 FPV
Camera input power: DC 5-40V
Size: 19mm*19mm*20mm - AEOLUS 2306.5 Engine
Engine: KV1900 6S
Input voltage: 3-6S
Recommended blade: 5 inches - HQProp&Ethix S5 5 inch 3 blade propeller
Quantity: 4 CW and 4 CCW The - Battery Connector: XT60
Package Included
- 1x HGLRC Sector X5 FR Frame
- 1x Zeus F722 mini FC
- 1x Zeus 45A V2 4in1 ESC
- 1x Zeus 800mW VTX
- 1x Caddx Ratel 2 FPV Cam
- 4x AEOLUS 2306.5 Engine
- 8x HQProp&Ethix S5 Propellers
- 1x SMA Hammer Antenna (RHCP)
- 1x M80 GPS
- 1x Receiver (optional)
Recommended battery: 6S/1200mah-1300mAh
