TAKER G4 35A is a newly developed AIO flight controller developed by GEPRC team. It adopts G473 main controller and has more redundant computing power.
In response to market demand, the TYPE-C interface has been upgraded, and the power pad and motor wire pad have been optimized to make welding easier. It is compatible with two 25.5-26.5mm mounting holes and can be compatible with more frames.
We are committed to making smaller, lighter and more powerful flight controllers.
Characteristics
- Compact size and compatible mounting holes make installation convenient.
- Lightweight, only 7.7g.
- G473 main control, 170MHz operating frequency, high computing power.
- Improved USB Type-C for greater versatility.
Specifications
- Model Name: TAKER G4 35A AIO
- Motherboard: STM32G473CEU6
- Serial Number: ICM 42688-P
- Target firmware: TAKERG4AIO
- OSD: Betaflight OSD with AT7456Ev
- Uart: R1 T1 / R2 T2 / R4 T4 / R5 T5
- Buzzer: YES
- LED: YES
- USB: USB Type-C
- BEC Output: 5V@3A
- MCU ESC: BB21F16G
- Continuous current: 35A
- Shock current: 45A (5")
- Input voltage: 2~4S (LIPO battery)
- Supports: Dshot600, Oneshot, Multishot
- Current meter: YES
- target: J -H -15
- Dimensions: 33.4×34.4 mm Card
- Installation hole: 25.5-26.5Φ3.05mm
- Weight: 7.7 g
Package Included
- 1x GEP-TAKER G4 35A AIO
- 1x Cable Set
