The new Flywoo TCXO 2.4G ELRS uses a temperature-compensated crystal oscillator to improve the clock frequency accuracy of the MCU, thereby improving the performance and reliability of the RC link. It allows for longer control distances, allowing users to operate devices within a wider range. This module boasts low latency and high refresh rates.
The TCXO EL24E features an integrated SMD antenna, while the EL24P includes an IPEX connector for a dipole antenna. Both modules are based on the ESP8285 MCU and can be updated via WiFi. They are also equipped with the IMLTRT SX1280 (or SX1281) RF module.
Highlights
- Improves the accuracy of the MCU clock rate
- Improves RC link performance and reliability
- Allows longer control distances
- Low latency and high refresh rates
- EL24E: integrated SMD antenna
- EL24P: IPEX connector for dipole antenna
- Based on the ESP8285 MCU
- Upgradeable via Wi-Fi
- Equipped with IMLTRT SX1280 (or SX1281) RF module.
Specifications
- Type: ISM2.4 GHz
- ESP8285 MCU
- SX1280(SX1281)IMLTRT RF module
- Frequency range: 2400 MHz to 2500 MHz
- Receive refresh rate: 25HZ ~ 500Hz
- Working voltage: 5V
- Weight: 0.44 grams (without antenna)
- Size: 10mm x 10mm x 6mm
- Communication protocol: CRSF (Betaflight)
- Peak Gain: 3.7dB
Firmware
- Default firmware out of factory: Flywoo EL24E 2.4GHz RX 3.0.0
- Integrated TCXO (temperature compensated crystal oscillator)
Package Included
- 1 Flywoo TCXO 2.4G ELRS EL24E
- 1 x Silicone Cable
- 1 x Heat Shrink Tubing
or - 1 Flywoo TCXO 2.4G ELRS EL24P
- 1 x Silicone Cable
- 1 heat shrink tubing
- 1 x XT antenna
