Characteristics
- Compatible with all major FPV receivers from vendors such as Fatshark, ImmersionRC, etc.
- Supports standard 40 channel set: A, B, E band, Fatshark and Raceband.
- The SmartAudio input allows remote control by the flight controller. Change channels, transmit power and more from Betaflight OSD, flight controller USB port, Taranis Lua Script and more.
- All parameters are controllable via button on the side of the unit, for cases where SmartAudio is not used.
- The MMCX connector is durable and easy to use. Rated for 100's of mating cycles. Quick and easy antenna replacement. No more torn UFL connectors.
- LED indicators for channel, band and power. Allows easy control of vTX parameters by simply glancing at the quad.
- Transmission power variable from 25 mW to 800 mW. Use 25 mW for a race and then easily switch to 800 mW for freestyle.
- 0.5mW True Pit mode allows you to power up safely without the risk of knocking other riders out of the air.
- Built-in microphone, so you can listen to your engines while flying, no matter how far you fly.
- The standard 26mm form factor allows the Atlatl to be mounted directly on the flight controller stack.
specifications
- Output Power: 0.5mW (pit mode), 25mW, 200mW, 500mW, 800mW
- Audio: 6.5 MHz Mono
- Antenna connector: MMCX
- Input voltage: 7 to 28 volts (2-6S LiPo)
- Dimensions: 30x26x7mm
- Mounting Holes: Standard 20mm square in center of holes
- Weight: 3.6g
Package Included
VTx card *1
80mm SMC cable - MMCX * 1 cable
80mm SMA - MMCX * 1 cable
JST GH 150mm 4pin *1
